Volume and plot...

Kitonum 21952
September 08 2024
2 3

Here is a simple calculation of the volume of this body and its drawing. Your body is like a torus. First we calculate the volume of this "torus" without a hole, and then simply subtract the volume of the hole. For drawing we use parametric equations of the surface of this body. For clarity, a cutout of 1/4 of the body is made.

restart;
f:=y->y^2-3: g:=y->y-y^2:
int(Pi*(2-f(y))^2, y=-1..3/2)-int(Pi*(2-g(y))^2, y=-1..3/2); # The volume of the solid
evalf(%);
M:=<cos(t),-sin(t); sin(t),cos(t)>:
P1:=plot3d([convert(M.<f(z)-2,0>, list)[1]+2, convert(M.<f(z)-2,0>, list)[2], z], t=-Pi/2..Pi, z=-1..3/2, color="Blue", scaling=constrained, axes=normal):
P2:=plot3d([convert(M.<g(z)-2,0>, list)[1]+2, convert(M.<g(z)-2,0>, list)[2], z], t=-Pi/2..Pi, z=-1..3/2, color="Red", scaling=constrained, axes=normal):
L:=plottools:-line([2,0,-2.9],[2,0,2.9], color=green, linestyle=3, thickness=2):
plots:-display(P1, P2, L, view=[-4.3..8.1,-6.1..6.1,-2.1..3.1]);





Inconsistent system...

Kitonum 21952
September 06 2024
0 0




>

restart; _local(D); sys := {F*b+L*c+Q*d+V*d2+a^2 = 1, G*b+M*c+R*d+W*d2+a*b = 0, H*b+N*c+S*d+X*d2+a*c = 0, B*a+H2*b+O*c+T*d+Y*d2 = 0, B*f+H2*g+O*h+T*h2+Y*k = 0, B*l+H2*m+O*n+T*o+Y*p = 0, B*q+H2*r+O*s+T*t+Y*u = 1, B*v+H2*w+O*x+T*y+Y*z = 0, C*a+K*b+P*c+U*d+Z*d2 = 0, C*f+K*g+P*h+U*h2+Z*k = 0, C*l+K*m+P*n+U*o+Z*p = 0, C*q+K*r+P*s+U*t+Z*u = 0, C*v+K*w+P*x+U*y+Z*z = 1, F*g+L*h+Q*h2+V*k+a*f = 0, F*m+L*n+Q*o+V*p+a*l = 0, F*r+L*s+Q*t+V*u+a*q = 0, F*w+L*x+Q*y+V*z+a*v = 0, G*g+M*h+R*h2+W*k+b*f = 1, G*m+M*n+R*o+W*p+b*l = 0, G*r+M*s+R*t+W*u+b*q = 0, G*w+M*x+R*y+W*z+b*v = 0, H*g+N*h+S*h2+X*k+c*f = 0, H*m+N*n+S*o+X*p+c*l = 1, H*r+N*s+S*t+X*u+c*q = 0, H*w+N*x+S*y+X*z+c*v = 0}; LL := {A, B, C, D, D2, F, G, H, H2, K, L, M, N, O, P, Q, R, S, T, U, V, W, X, Y, Z}; MM := LinearAlgebra:-GenerateMatrix(sys, LL); LinearAlgebra:-LinearSolve(MM)

Error, (in LinearAlgebra:-LinearSolve) inconsistent system


>

``




Download Count_operations_new.mw

Dihedral angle of two halfplanes...

Kitonum 21952
September 04 2024
1 4

To solve this, we can follow the plan:
1. Take a point M inside the pyramid - we can take any linear convex combination of the pyramid's vertices.
2. Find the projections of this point M1 and M2 onto the desired planes.
3. Find the angle alpha between the vectors MM1 and MM2.
4. The required angle is Pi - alpha.

restart;
local D:
with(Student:-MultivariateCalculus):
A, B, C, D, S :=  [0,0,0], [1,0,0], [1,1,0], [0,1,0], [0,0,1]:
p1, p2 := Plane(S,B,C), Plane(S,C,D):
M:=(A+B+C+D+S)/5;
M1:=Projection(M, p1);
M2:=Projection(M, p2);
v1:=convert(M1-M,Vector);
v2:=convert(M2-M,Vector);
Pi-Angle(v1,v2);  # The answer





Another way...

Kitonum 21952
September 04 2024
1 0
data[2 .. 3];



Area...

Kitonum 21952
August 29 2024
1 0

This figure is not bounded and its angles go to infinity in three directions. Therefore, to accurately calculate the area, the integration limits should be changed:

restart;
y0 := -ln(1 - exp(-x)):
y1 := -ln(-1 + exp(-x)):
y2 := -ln(1 + exp(-x)):
Area := int(y1-y2, x=-infinity..0) + int(y0-y2, x=0..infinity);
evalf(Area);







Solution...

Kitonum 21952
August 24 2024
2 0
restart;
Square:=proc(t, r)
local A, B, M, N, v, R, P, c, s, T;
uses plots, plottools;
A := [-r, 0];
M := <r*cos(t), r*sin(t)>;
v:=M-convert(A,Vector);
R:=<cos(Pi/2),-sin(Pi/2); sin(Pi/2),cos(Pi/2)>;
N:=M + R.v;
P:=N - v;
M, N, P := convert~([M, N, P], list)[];
c:=circle(r, color = blue);
s:=curve([A,M,N,P,A], color=red);
T:=textplot([[A[],"A"],[r,0,"B", align=right],[M[],"M"],[N[],"N"],[P[],"P"]], font=[times,16], align={left,above});
display(c, s, T, scaling=constrained, thickness=2);
end proc:

plots:-animate(Square, [t,1], t=0..2*Pi, frames=90);





`if`...

Kitonum 21952
August 24 2024
1 0




>

restart;
>

v := 1: a := 0: b := 1: t := 0.1e-2: dt := 0.1e-3: N := 5: h := (b-a)/(N-1):
>

for i to N do x[i] := a+(i-1)*h end do:
p := x->product(x-x[k], k = 1 .. N);
f := expand(p(x));

proc (x) options operator, arrow; product(x-x[k], k = 1 .. N) end proc



x^5-(5/2)*x^4+(35/16)*x^3-(25/32)*x^2+(3/32)*x

 (1)
>

PRime := diff(f, x);

5*x^4-10*x^3+(105/16)*x^2-(25/16)*x+3/32

 (2)
>

for i to N do
for j to N do
 if i <> j then a[i, j] := (eval(PRime, x = x[i]))/((x[i]-x[j])*(eval(PRime, x  = x[j]))) else
 a[i, j] := -add(`if`(k<>i, a[i, k], undefined), k = 1 .. N) end if;
 end do:
 end do:
>

seq(seq(a[i,j], i=1..N), j=1..N);

undefined, -1, 1/3, -1/3, 1, 16, undefined, -8/3, 2, -16/3, -12, 6, undefined, -6, 12, 16/3, -2, 8/3, undefined, -16, -1, 1/3, -1/3, 1, undefined

 (3)
>






Download burgers_type_method_new.mw

Circle passing through points C, D, K, H...

Kitonum 21952
August 13 2024
0 0

A circle does not necessarily pass through 4 points, even if the points lie in the same plane. Therefore, we first find the center of the circle passing through points C, D, H, and then check that point K also lies on the same circle:




>

restart;
_local(D, O);
with(Student:-MultivariateCalculus):
A := [0, 0, 0];
B := [a, 0, 0];
C := [a, b, 0];
D := [0, b, 0];
S := [0, 0, h];
O := [x, y, z];
lineSC := Line(S, C);
lineSD := Line(S, D);
H := Projection(A, lineSC);
K := Projection(A, lineSD);
OH := H - O;
OK := K - O;
OC := C - O;
M := Matrix([OH, OK, OC]);
E:=(C+D)/2;
F:=(C+H)/2;
p1:=Plane(E,convert(C-D,Vector));
p2:=Plane(F,convert(C-H,Vector));
Eq1:=GetRepresentation(p1);
Eq2:=GetRepresentation(p2);
Md:=LinearAlgebra:-Determinant(M);
solve({Eq1,Eq2,Md}, {x,y,z});
O := eval(O, %);
d:=simplify(Distance(O, H));
d1:=simplify(Distance(O, K));
is(d=d1);

A := [0, 0, 0]



B := [a, 0, 0]



C := [a, b, 0]



D := [0, b, 0]



S := [0, 0, h]



O := [x, y, z]



Student:-MultivariateCalculus:-Line([0, 0, h], Vector(3, {(1) = a, (2) = b, (3) = -h}), variables = [x, y, z], parameter = t, id = 1)



Student:-MultivariateCalculus:-Line([0, 0, h], Vector(3, {(1) = 0, (2) = b, (3) = -h}), variables = [x, y, z], parameter = t, id = 2)



H := [h^2*a/(a^2+b^2+h^2), h^2*b/(a^2+b^2+h^2), h*(a^2+b^2)/(a^2+b^2+h^2)]



K := [0, h^2*b/(b^2+h^2), h*b^2/(b^2+h^2)]



OH := [-x+h^2*a/(a^2+b^2+h^2), -y+h^2*b/(a^2+b^2+h^2), -z+h*(a^2+b^2)/(a^2+b^2+h^2)]



OK := [-x, -y+h^2*b/(b^2+h^2), -z+h*b^2/(b^2+h^2)]



OC := [-x+a, -y+b, -z]



Matrix(3, 3, {(1, 1) = -x+h^2*a/(a^2+b^2+h^2), (1, 2) = -y+h^2*b/(a^2+b^2+h^2), (1, 3) = -z+h*(a^2+b^2)/(a^2+b^2+h^2), (2, 1) = -x, (2, 2) = -y+h^2*b/(b^2+h^2), (2, 3) = -z+h*b^2/(b^2+h^2), (3, 1) = -x+a, (3, 2) = -y+b, (3, 3) = -z})



E := [(1/2)*a, b, 0]



F := [h^2*a/(2*(a^2+b^2+h^2))+(1/2)*a, h^2*b/(2*(a^2+b^2+h^2))+(1/2)*b, h*(a^2+b^2)/(2*(a^2+b^2+h^2))]



Student:-MultivariateCalculus:-Plane(Vector(3, {(1) = a, (2) = 0, (3) = 0}), [(1/2)*a, b, 0], variables = [x, y, z], id = 1)



_m2776775710912



x = (1/2)*a



(-h^2*a/(a^2+b^2+h^2)+a)*x+(-h^2*b/(a^2+b^2+h^2)+b)*y-h*(a^2+b^2)*z/(a^2+b^2+h^2) = (-h^2*a/(a^2+b^2+h^2)+a)*((1/2)*h^2*a/(a^2+b^2+h^2)+(1/2)*a)+(-h^2*b/(a^2+b^2+h^2)+b)*((1/2)*h^2*b/(a^2+b^2+h^2)+(1/2)*b)-(1/2)*h^2*(a^2+b^2)^2/(a^2+b^2+h^2)^2



-h^2*a*(a^2*b*h-a^2*b*z-a^2*h*y+b^3*h-b^3*z-b^2*h*y)/((a^2+b^2+h^2)*(b^2+h^2))



{x = (1/2)*a, y = (1/2)*b*(b^2+2*h^2)/(b^2+h^2), z = (1/2)*h*b^2/(b^2+h^2)}



[(1/2)*a, (1/2)*b*(b^2+2*h^2)/(b^2+h^2), (1/2)*h*b^2/(b^2+h^2)]



(1/2)*(((b^2+h^2)*a^2+b^4)/(b^2+h^2))^(1/2)



(1/2)*(((b^2+h^2)*a^2+b^4)/(b^2+h^2))^(1/2)



true

 (1)
>






Download center_circle.mw

Empty symbol...

Kitonum 21952
August 08 2024
2 1

In this example, it's easier to do it manually, using the empty symbol  ``   to prevent automatic bracket expansion:

restart;
p:=9*csc(theta)^2+9;
9*``(p/9);



evala...

Kitonum 21952
August 02 2024
0 2
evala(M);



Solution...

Kitonum 21952
August 02 2024
1 0

You can use a special program for this. See  https://mapleprimes.com/posts/200677-Partition-Of-An-Integer-With-Restrictions

Examples of use:

Partition(10, 4, 1..4);  # Your problem.
``;
Partition(10, 4, {1,3,5,7,9});  # Partitions of length 4 consisting only of odd numbers.
``;
Partition(10, 1..10, {1,3,5,7,9});  # Any partitions of odd numbers.







Easier...

Kitonum 21952
July 19 2024
2 4
A:=int(x^(1/2),x);
sqrt(A^2);



We used the fact that for any non-negative real number  A = sqrt(A^2) . This technique is often useful.

op...

Kitonum 21952
July 17 2024
1 0

The  has(a, b)  command returns true if  b  is an operand of  a  of some level (in this case we say that  b  is a subexpression of  a ) . The operands are returned by the op command. See

restart;
A:=I/sqrt(a);
B:=op(A);
op(B[2]);
has(A,a^(-1/2));
has(A,-1/2);



rem...

Kitonum 21952
July 10 2024
1 1

In the help for the  Algebraic:-Remainder(a, b, x, options) command it is written: "The arguments a and b must be univariate polynomials in the variable x, which is typically a name. If other names or non-algebraic sub-expressions are included and they cannot be evaluated to algebraic numbers, an "unable to divide multivariate polynomials" error will be returned". So use he standard command  rem :

restart;
rem(a*x^3 + b*x^2 + c*x + d, 3*a*x^2 + 2*b*x + c, x);



Empty symbol...

Kitonum 21952
July 09 2024
3 1

Use the  empty symbol  ``  for this.

Example:

restart;
plot(sqrt(x), x = 0 .. 4, tickmarks = [[seq(i=``,i=0..4)], [seq(i=``,i=0..2)]], scaling=constrained);
