If you execute the Maple command,

libname;

then you should be able to figure out where the `lib` folder resides.

If you don't want to mess around with the folder belonging to your installed Maple then you could try placing them in a folder which you place as follows: First, find out what Maple considers to be your home folder, by executing the Maple command,

kernelopts(homedir);

Append the result of that with something like /maple/toolbox/Trig/lib" and create those folders (relative to whatever kernelopts(homedir) reported, naturally).

In any case, once the two files are copied into location, close and relaunch Maple.

You would need both of your files Trig.lib and Trig.ind as they form a Maple archive together. (In modern Maple such an archive would usually created as a single file named Trig.mla but whoever wrote your pair is doing it the old way.)

acer

A simple way (though likely not the most efficient, if you want to do it thousands of times),

A:=<2,3>;

                                       [2]
                                  A := [ ]
                                       [3]

A . <1,1>;

                                      5

acer

Try changing the call to dsolve(...,numeric) to be,

sol1 := dsolve({DE1, DE2, ICs, a(t) = diff(x(t), t, t)}, numeric, range = 0 .. 3);

Then, your last plot could be produced using,

odeplot(sol1, [t, a(t)], 0 .. N);

That could be a way to get better results, numerically. It makes dsolve(...,numeric) compute a(t) itself. By instead using D(v)(t) then when that gets evalf'd Maple will internally call fdiff() to compute a derivative numerically using a multi-point difference scheme. I would expect dsolve(...,numeric) to be able to compute a(t) more robustly than that, in general if not specifically.

acer

Please check whether these results are plausible and accurate enough, etc.

dsparint2.mw

This revision of code as attached worksheet, including plots out to t=48, takes approximately 61 sec in 64bit Maple 15 on Windows 7 running on an Intel i7 930.

The call to forget(`evalf/int`) is necessary when using operator form for the integrand passed to evalf(Int(..)), if that integrand evaluates according to some hidden quality such as the setting of earlier dsolve/numeric parameters.

I believe that the call to forget(evalf) may not be necessary and so I removed it. That brought a big performance change (if accompanied by the other edits). I don't know for sure that evalf is not storing any results mistakenly (by ignoring the hidden depencies upon the parameters of the earlier dsolve/numeric output procs). I didn't have the patience to wait the long time to get final results using your posted code.

I changed it to use evalf(Int(...)) instead of evalf(int(...)). But to do that, with the forced method=_d01ajc, I had to workaround what appears to be a bug in evalf/Int. It looks like an internal evalf/Int routine might be unprepared to catch & handle a particular error coming out of evalhf when trying to run the earlier dsolve/numeric stuff during evaluation of the integrand. And so it doesn't seem able to gracefully fall back to regular evalf mode. I (believe) that I worked around this by the unusual maneouver of turning the integrand into a procedure which is deliberately non-evalhf'able (viz. it creates an empty list) and which would throw a different but recognized evalhf error. Blech.

And I made a few adjustments to try and tone down some of the accuracy tolerances.

nb. I only changed Po2m to something usable, since Pco2m doesn't seem needed by the final dsolve.

The final plot of O2r looks a bit different in Maple 16 than it does in Maple 15, especially in the key t=15..25 range. The other four plotted functions of t looked pretty much the same in both versions. But in Maple 16 O2r doesn't really fall below 0.00004 whereas in Maple 15 it gets down to -0.0004 or so. I didn't try another solver for dsolve/numeric. But this discrepency seems to persist even if I adjust the final dsolve relerr to be 1e-9 and the evalf/Int epsilon to be 1e-11.

acer

w:=-t*sin(x*Pi): # or what have you...

A:=plots:-animate(w, x=0..1, t=0..0.1, frames=50, numpoints=100,
                  color=red, thickness=3, view=[0..1,-1..1]):

plots:-display(A, view=[0..1,-1..1], insequence=true);

plots:-display(plottools:-transform((x,y)->[y,x])(A),
               view=[-1..1,0..1], insequence=true);

acer

See the help-page evalf,Int which is also cross-referenced from the 5th bullet point in the Description section of the help-page for int.

For some other  examples you could look again at a response to your question from last week.

acer

In Maple 16.00 running on Windows 7 with 6GB RAM available, I get results as follows from kernelopts(bytesalloc),  for a single set of attempts.

32bit Maple: n=100  171MB

64bit Maple: n=100  264MB

acer

You could use plots:-odeplot,

gamma1:=1:
gamma2:=1:

l:=t->sqrt((x1(t)-x2(t))**2+(y1(t)-y2(t))**2):

DE:=[diff(x1(t),t)=(-1/(2*Pi))*gamma2*(y1(t)-y2(t))/l(t),
     diff(y1(t),t)=(-1/(2*Pi))*gamma1*(x1(t)-x2(t))/l(t),
     diff(x2(t),t)=(-1/(2*Pi))*gamma2*(y2(t)-y1(t))/l(t),
     diff(y2(t),t)=(-1/(2*Pi))*gamma1*(x2(t)-x1(t))/l(t)]:

plots:-odeplot(dsolve({DE[],x1(0)=1,x2(0)=-1,y1(0)=1,y2(0)=0},numeric),
               [[x1(t),y1(t)],[x2(t),y2(t)]],t=0..50,frames=25,
               color=[gold,gold],thickness=2);

acer

Don't break the long name that looks like `#mrow...`

with(Statistics):
BoxPlot([seq(Sample(Normal(ln(i), 3), 100), i = 1..20)],
title = `#mrow(mi("Jan 2011",mathcolor="#ff00ff"),mi(" --- "),mi("Dec 2011",mathcolor="#005555"))`,
color="ff00ff".."005555",deciles = false);

Another example, building up that long TypeMK name (which you could also do with a procedure),

clr1:="#999900":
clr2:="#009999":

Statistics:-BoxPlot(
    [seq(Statistics:-Sample(Normal(ln(i),3),100),i=1..10)],
    title = cat(`#mrow(`,
            `mi("Jan 2011",mathcolor=\"`,clr1,`\")`,
            `,`,
            `mi(" --- ")`,
            `,`,
            `mi("Dec 2011",mathcolor=\"`,clr2,`\")`,
             `)`),
    color = clr1..clr2, deciles = false);

acer

The explanation is confusing. Did you mean to say instead that the entries of N1, N2... are expressions in terms of `eta`?

Are you trying to map the `int` or `Int` commands over N1,N2... with eta=eta0..eta2 being the extra argument? If so that the syntax is not right. It should be something like map(int,N1,eta=eta0..eta2) or map(Int,N1,eta=eta0..eta2), in that case.

Do you have somethin like this, but for 3x3 Matrices,

N1:=Matrix([[eta,eta^2],[sin(eta),cos(eta)*eta]]);

                             [                 2    ]
                             [  eta         eta     ]
                       N1 := [                      ]
                             [sin(eta)  cos(eta) eta]

L:=[eta0=8.3,eta2=666];

                        L := [eta0 = 8.3, eta2 = 666]

# First way: inert integral with parameters substituted by
# values, then numerical integration performed.
# Be careful with syntax. And note Int not int.
E1:=map(Int,N1,eta=eta0..eta2):
eval(E1,L):
evalf(%);

                     [              5                7]
                     [2.217435550 10   9.846924140 10 ]
                     [                                ]
                     [   -1.431221219     -17.80614111]

# Alternatively, exact integration attempted, followed by
# floating-point evaluation of that result.
E1:=map(int,N1,eta=eta0..eta2):
eval(E1,L):
evalf(%);

                     [              5                7]
                     [2.217435550 10   9.846924140 10 ]
                     [                                ]
                     [   -1.431221219     -17.80614111]

In both ways, you don't have to assign to `eta0` or `eta2`, or change the names used. You just have to build the various lists L.

acer

You have an E(T) which should likely be E(t). You need to use the infix `union` command to merge the sets `dsys` and `isc`.

I changed e^7 to exp(7) which how one exponentiates the base of the natural logarithm in Maple. Or did you intend to use `e` as a variable parameter?

restart;

dsys := {diff(E(t), t) = -kf*E(t)*S(t)+kr*ES(t)+kcat*ES(t),

                diff(ES(t), t) = kf*E(t)*S(t)-kr*ES(t)-kcat*ES(t),

                diff(P(t), t) = kcat*ES(t),

                diff(S(t), t) = -kf*E(t)*S(t)+kr*ES(t)};

kf := 10^6; kr := 10^(-4); kcat := .1;

isc := {E(0) = 2/exp(7), ES(0) = 0, P(0) = 0, S(0) = 5/exp(7)};

dsol := dsolve(dsys union isc, numeric, method = gear[polyextr],
                initstep = 0.15e-1, minstep = 10^(-11),
                abserr = 0.1e-4, relerr = 0.1e-5);

acer

It's a square.

factor(dell);

                                         2
                      /          (1/2)  \
                      \-a + 9 + 6      b/

acer

You have X with 8 entries and Y with 9 entries.

Does it help if you reduce the number of entries of Y by one, so as to match that of X?

acer

Try FileTools:-Text:-ReadFile

acer

M := Matrix([[1,2],[3,4],[5,6]]);


                                      [1  2]
                                      [    ]
                                 M := [3  4]
                                      [    ]
                                      [5  6]

M . Vector([1/2,1/2]);

                                    [ 3]
                                    [ -]
                                    [ 2]
                                    [  ]
                                    [ 7]
                                    [ -]
                                    [ 2]
                                    [  ]
                                    [11]
                                    [--]
                                    [2 ]

M . Vector([0.5,0.5]);

                             [1.50000000000000]
                             [                ]
                             [3.50000000000000]
                             [                ]
                             [5.50000000000000]

acer
