@justauser
Physics has Fundiff, to compute Lagrange equations in general by variating the Action as an integral of the Lagrangian density. It is true, however, that none of these three packages have a command to tackle the inverse problem, that is, to find the Lagrangian given Lagrange's equations (am I right in understanding that is what you want?)

At first sight, I would think that a direct approach, formulating the problem with L as an unknown, then tackling the system of equations with PDEtools commands, would be the way to go, instead of computing the Helmholtz conditions for the existence of the Lagrangian to then try to compute the Lagrangian itself. If Helmholtz conditions are not satisfied, the PDEtools commands will automatically return nothing.

Could you please write, within a Maple worksheet, who your 'vg' is and what solution (Lagrangian) you expect and upload the worksheet? (For that, use the green arrow you see when posting something here.) If you do not know what you expect, could you please add in that worksheet an example where you give vg and the solution you expect? With that, I can take a look

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

Hi @Carl Love
I am saying it is a different problem, but not just that: I fixed both problems in two different places. One is: simplifying a RootOf returned by solve may, rarely but can happen, result in a RootOf("...") where "..." has no _Z around. The other is: due to a bug in solve in 1999, there was a line of code removing solutions x = x for single equation problem. That bug got fixed in 2000, but that line in the internal differential equation (solve) routine remained in place. Then you posted what, for me, is a valid example of solution x = x, not related to RootOf(...) that has no _Z. So: two problems that required two fixes. That explains in detail why I wrote "these are two different and unrelated problems."

Then your view on this, that "something", solved with respect to x, could not have x when "something" is simplified, yes, in that sense, there is similitude; your message, however, didn't say that. Instead: "here is another one where solve and PDEtools:-Solve return different, and I (Carl) prefer the output by solve".

@Rouben Rostamian@nm

I deleted my previous comment, "uses" Physics:-Vectors is not necessary in Rouben's program, but anyway I preferred to look at this closely. The issue is now resolved in the Maplesoft Physics Updates v.1276.

The details are:

1) Vectors:-`-`  (not a Vectors visibly exported command) is an internal routine coded as a hidden export. I would expect not to be binded by uses, but it is. Maybe my expectation is due to my lack of familiarity with uses, a useful and straightforward idea.

2) Vectors:-`-` was coded (~30 years ago) as a binary operator. Used as an internal routine, that is all that was needed. But the same way as `+`, the `-` operation is well defined with 0, 1 or N > 1 operands.

3) Within Rouben's program, "1 - p.q" is an operation (`-`) with two operands, not just one, but when "uses" is there, Vectors:-`-` receives only one operand, resulting, due to 2), in the error interruption observed. You see that by entering debug(Vectors:-`-` ) before entering my_module:-my_proc(u_,v_). If, in Rouben's program, instead of `-` you use `+`, then debug(Vector:-`+`), you see that two operands are passed to Vectors:-`+`, not just one. (Unlike Vectors:-`-`, Vectors:-`+` is a Vectors visibly exported command, expected to be binded by uses.) So up to what I can see there is an issue in "uses" here: it passes two operands to `+`, but only one to `-`.

Item 2) is corrected by removing the (unnecessary) restriction to "always expect 2 operands"; with that, the problem noticed disappears entirely. Item 3) is now tracked as an issue in uses, to be reviewed by the kernel group.

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft



Hi @Rouben Rostamian

The Maple default type 'scalar', as several commands previous to Physics, knows nothing about this extended domain that includes vectors, tensors, abstract matrices (non-commutative symbols) etc. Instead of that, please check the help page for Vectors:-Identify. That is what you need to distinguish a scalar from a vector.

To the side: Physics and its subpackages are self-complete, including, in addition to the package's commands, the Physics:-Library (nops(with(Physics:-Library)) -> 172) and the library of Physics types (nops(with(Physics:-Library:-PhysicsTypes)) -> 114). Those are the internal routines and types with which the Physics package and its subpackages are written.

Of course, there are Maple commands that exist before Physics, and you can use all of them when writing code for the extended domain implemented with Physics, but depending on the (pre-Physics) command or type, you need to first check that they work as you intend. In part for that reason, I made the whole Physics:-Library and its types available and documented at user level - they allow you to code everything you'd need to compute with the extended domain.

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft





Hi Rouben,

Having a unique zero is an intentional design, not a mistake, not a bug nor something of the like.



First, note that the error message you show is due to the way you programmed your procedure f enforcing a type checking of its argument that only accepts a vector (what you'd call a non-zero vector). For example, if instead of that you accept input of type algebraic and use Vectors:-Norm, you have the f you seem to have tried to program



with(Physics:-Vectors)



f := proc (q::algebraic) options operator, arrow; Norm(q)^2 end proc

proc (q::algebraic) options operator, arrow; Physics:-Vectors:-Norm(q)^2 end proc

(1)

f(a_)

Physics:-Vectors:-Norm(a_)^2

(2)

f(k*a_)

Physics:-Vectors:-Norm(k*a_)^2

(3)

expand(%)

k^2*Physics:-Vectors:-Norm(a_)^2

(4)

f(0*a_)

0

(5)

All the product and sum operations between objects of type algebraic are well defined with 0

0+a_

a_

(6)

0.a_

0

(7)

`&x`(0, a_)

0

(8)

In this context, distinguishing between the algebraic 0 you see in (7) and the algebraic 0 you see in (8) is of no use, not for the purpose of performing algebraic computations (computing with objects of type algebraic). Such a distinction would then be artificial; an unnecessary complication.



Regarding your comment about other packages, VectorCalculus and LinearAlgebra compute with matrix representations of vectors, and there is indeed a computational distinction between the number 0 and a matrix all of whose components are equal to 0; so these two packages need to distinguish between the number 0 and a "0 vector" (represented as a column matrix of zeros). One of the main disadvantage of the matrix representation of vectors is that you cannot compute with the basic object A_, a non-projected vector, as you do when computing with Physics:-Vectors.



By the way, one of the key design differences between Physics and other packages is that, in Physics, instead of restricting the representations of mathematical objects to scalars or matrices, the domains of the operations were extended to handle the objects we use when computing with paper and pencil. That includes abstract vectors, tensors, Einstein's sum rule for repeated indices, anti-commutative and non-commutative objects, spinors, etc. All these objects, not present in the standard domain of computer algebra systems before Physics, are implemented with type algebraic. The number of advantages of having all these objects of type algebraic (when that is possible) is too large to list here, but for me the main one is that it allows for the closest match between what we do when computing with paper and pencil and what we can now do on a computer algebra worksheet.



If regardless of the above you still want to have a type that includes 0 as a vector you can use Or(0, PhysicsVectors). Then your procedure f will work as you planned, and in addition you can assign a name to this combo, as in TPV := Or(0, PhysicsVectors).

Download unique_zero.mw

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft



@bikramphy

You have now added information, the metric, OK. Below is basically the same worksheet, with small changes, taking into account the form of the metric.



with(Physics); with(Tetrads)

_______________________________________________________

(1)

Simplify steps setting the signature as close as possible to the one you want, and set coordinates as you now indicated they are

Setup(signature = "+++-", coordinates = (X = [Q, q, u, t]))

[coordinatesystems = {X}, signature = `+ + + -`]

(2)



Input the metric that you are now indicating

ds2 := dQ*dq+dQ*dq+du*dt+du*dt-Typesetting[delayDotProduct](2*Q/m.(diff(V(q, t), q)), dt, true)*dt

2*dQ*dq+2*du*dt-2*Q*(diff(V(q, t), q))*dt^2/m

(3)

Set compact display to make things more readable

CompactDisplay(2*dQ*dq+2*du*dt-2*Q*(diff(V(q, t), q))*dt^2/m)

V(q, t)*`will now be displayed as`*V

(4)

Setup(metric = ds2)

[metric = {(1, 2) = 1, (3, 4) = 1, (4, 4) = -2*Q*(diff(V(q, t), q))/m}]

(5)

The tetrad computed by default is orthonormal

e_[]

Physics:-Tetrads:-e_[a, mu] = Matrix(%id = 36893488153642513460)

(6)

"IsTetrad(?)"

true

(7)

From

e_[definition]

Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[b, `~mu`] = Physics:-Tetrads:-eta_[a, b]

(8)

You see the form of the tetrad metric eta[a, b] that indicates the signature, is "(+++-)"

e_[a, mu]*e_[b, mu]; % = TensorArray(%, simplifier = `@`(simplify, evala))

Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[b, `~mu`] = Matrix(%id = 36893488153619389964)

(9)

You need to find a matrix A such that when redefining the tetrad as A * e_ = E, and substituting into the above, you get "E[a,mu] E[b]^(mu)=([[[1,0,0,0],[0,1,0,0],[0,0,-1,0],[0,0,0,-1]]])", where in the right-hand side you see the signature "(++--)".


I'd search for a matrix of this form, adding one element out of the diagonal, mostly for illustration purposes (you see in the result that was actually not necessary)

A := subs(`~`[`=`]([a[1, 2], a[1, 3], a[1, 4], a[2, 4], a[3, 4]], 0), Matrix(4, symbol = a, shape = symmetric))

Matrix(%id = 36893488151942187836)

(10)

E[a, mu] = A.rhs(e_[])

E[a, mu] = Matrix(%id = 36893488151939865164)

(11)

Define this as a tensor, to use the tensor functionality to build a set of equations for the `a__i,j`

"Define(?)"

{Physics:-D_[mu], Physics:-Dgamma[mu], E[a, mu], Physics:-Psigma[mu], Physics:-Ricci[mu, nu], Physics:-Riemann[mu, nu, alpha, beta], Physics:-Weyl[mu, nu, alpha, beta], Physics:-d_[mu], Physics:-Tetrads:-e_[a, mu], Physics:-Tetrads:-eta_[a, b], Physics:-g_[mu, nu], Physics:-gamma_[i, j], Physics:-Tetrads:-gamma_[a, b, c], Physics:-Tetrads:-l_[mu], Physics:-Tetrads:-lambda_[a, b, c], Physics:-Tetrads:-m_[mu], Physics:-Tetrads:-mb_[mu], Physics:-Tetrads:-n_[mu], Physics:-Christoffel[mu, nu, alpha], Physics:-Einstein[mu, nu], Physics:-LeviCivita[alpha, beta, mu, nu], Physics:-SpaceTimeVector[mu](X)}

(12)

Introduce the expected form of the tetrad metric to build the set of equations to be solved for the `a__i,j`

Eta[a, b] = Matrix(4, 4, [[1, 0, 0, 0], [0, 1, 0, 0], [0, 0, -1, 0], [0, 0, 0, -1]])

Eta[a, b] = Matrix(%id = 36893488153673893876)

(13)

"Define(?)"

{Physics:-D_[mu], Physics:-Dgamma[mu], E[a, mu], Eta[a, b], Physics:-Psigma[mu], Physics:-Ricci[mu, nu], Physics:-Riemann[mu, nu, alpha, beta], Physics:-Weyl[mu, nu, alpha, beta], Physics:-d_[mu], Physics:-Tetrads:-e_[a, mu], Physics:-Tetrads:-eta_[a, b], Physics:-g_[mu, nu], Physics:-gamma_[i, j], Physics:-Tetrads:-gamma_[a, b, c], Physics:-Tetrads:-l_[mu], Physics:-Tetrads:-lambda_[a, b, c], Physics:-Tetrads:-m_[mu], Physics:-Tetrads:-mb_[mu], Physics:-Tetrads:-n_[mu], Physics:-Christoffel[mu, nu, alpha], Physics:-Einstein[mu, nu], Physics:-LeviCivita[alpha, beta, mu, nu], Physics:-SpaceTimeVector[mu](X)}

(14)

This is the identity you use to adjust the `a__i,j`

E[a, mu]*E[b, `~mu`] = Eta[a, b]

E[a, mu]*E[b, `~mu`] = Eta[a, b]

(15)

TensorArray(E[a, mu]*E[b, `~mu`] = Eta[a, b], simplifier = simplify)

Matrix(%id = 36893488153624419132)

(16)

"convert(?,setofequations)"

{0 = 0, a[1, 1]^2 = 1, a[2, 3]*(a[2, 2]+a[3, 3]) = 0, -a[4, 4]^2 = -1, a[2, 2]^2+a[2, 3]^2 = 1, a[2, 3]^2+a[3, 3]^2 = -1}

(17)

solve({0 = 0, a[1, 1]^2 = 1, a[2, 3]*(a[2, 2]+a[3, 3]) = 0, -a[4, 4]^2 = -1, a[2, 2]^2+a[2, 3]^2 = 1, a[2, 3]^2+a[3, 3]^2 = -1})

{a[1, 1] = 1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = 1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1}, {a[1, 1] = 1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = 1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1}, {a[1, 1] = -1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = -1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1}, {a[1, 1] = -1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = -1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1}

(18)

Any of these solutions serve your purpose, take the first one, remove that RootOf

sol := convert(({a[1, 1] = 1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = 1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1}, {a[1, 1] = 1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = 1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1}, {a[1, 1] = -1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = -1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1}, {a[1, 1] = -1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = 1}, {a[1, 1] = -1, a[2, 2] = -1, a[2, 3] = 0, a[3, 3] = RootOf(_Z^2+1), a[4, 4] = -1})[1], radical)

{a[1, 1] = 1, a[2, 2] = 1, a[2, 3] = 0, a[3, 3] = I, a[4, 4] = 1}

(19)

The tetrad that results in the tetrad metric "(++--)"is then given by

subs(sol, E[])

E[a, mu] = Matrix(%id = 36893488153642495860)

(20)

Set now this matrix as the tetrad

"Setup(tetrad = rhs(?))"

[tetrad = {(1, 1) = ((1/2)*I)*2^(1/2), (1, 2) = -((1/2)*I)*2^(1/2), (2, 3) = (1/2)*2^(1/2)/((Q^2*(diff(V(q, t), q))^2+m^2)^(1/2)/m)^(1/2), (2, 4) = -(1/2)*2^(1/2)*(Q*(diff(V(q, t), q))-(Q^2*(diff(V(q, t), q))^2+m^2)^(1/2))/(((Q^2*(diff(V(q, t), q))^2+m^2)^(1/2)/m)^(1/2)*m), (3, 3) = ((1/2)*I)*2^(1/2)/(-(Q^2*(diff(V(q, t), q))^2+m^2)^(1/2)/m)^(1/2), (3, 4) = -((1/2)*I)*2^(1/2)*(Q*(diff(V(q, t), q))+(Q^2*(diff(V(q, t), q))^2+m^2)^(1/2))/((-(Q^2*(diff(V(q, t), q))^2+m^2)^(1/2)/m)^(1/2)*m), (4, 1) = -((1/2)*I)*2^(1/2), (4, 2) = -((1/2)*I)*2^(1/2)}]

(21)

And that is all.



Verify now:

e_[]

Physics:-Tetrads:-e_[a, mu] = Matrix(%id = 36893488151918118900)

(22)

This is the tetrad metric you were looking for, associated to a signature of the form "(++--)"

eta_[]

Physics:-Tetrads:-eta_[a, b] = Matrix(%id = 36893488151947672860)

(23)

This is the tetrad definition

e_[definition]

Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[b, `~mu`] = Physics:-Tetrads:-eta_[a, b]

(24)

This definition is satisfied (by construction)

TensorArray(Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[b, `~mu`] = Physics:-Tetrads:-eta_[a, b])

Matrix(%id = 36893488153642493340)

(25)

This is the other way of the definition of the tetrad, relating it to the spacetime metric

e_[a, mu]*e_[a, nu] = g_[mu, nu]

Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[`~a`, nu] = Physics:-g_[mu, nu]

(26)

TensorArray(Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[`~a`, nu] = Physics[g_][mu, nu])

Matrix(%id = 36893488151942188916)

(27)

The equation components are all identities by eye, also by computer (useful when the expressions are difficult to read by eye).

"map(evalb,?)"

Matrix(%id = 36893488151918155164)

(28)

Summarizing: the procedure is the same one shown in the first reply, just that instead of solving the system by eye as I did from (6) to (7) of the previous workshet-reply (something correct in that simple case of Schwarzschild solution) you solve it using the computer as done above from (15) to (18), also arriving at a simple solution.



NULL




Download arbitrary_signature_(II).mw


Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

Hi, could you please upload a worksheet with the metric? You can use the green arrow for that.

Hi
Wikipedia mentions the DiracComb function. Anyone has an idea of how frequently used is this function? Maybe it is worth implementing it in Maple. Opinions?

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

May 27: Answer and add a worksheet showing how to do this with Physics

First the answer to your question: change you input

Oneform := RaiseLowerIndices(g, ON[1], [1])

by

Oneform := convert(RaiseLowerIndices(g, ON[1], [1]), DGform)

And that resolves the problem you encountered. Next is how you do the same computation using Physics

NULL

Delta := -2*M*R+R^2+a^2

Sigma2 := (R^2+a^2)^2-Delta*a^2*sin(Theta)^2

rho2 := R^2+a^2*cos(Theta)^2

z := 2*M*R/rho2



Load Physics

with(Physics)



Set the coordinates

Coordinates(X = [T, R, Theta, Phi])

`Systems of spacetime coordinates are:`*{X = (T, R, Theta, Phi)}



{X}

(1)

Set the metric, I am doing this in two steps so that you see how it is done: just remove the "&t" from around

`#msup(mi("ds"),mn("2"))` := (-1+z)*dT^2+dT*dR+dT*dR+rho2*dTheta^2-z*a*sin(Theta)^2*(dPhi*dT+dPhi*dT)-a*sin(Theta)^2*(dR*dPhi+dR*dPhi)+Sigma2*sin(Theta)^2*dPhi^2/rho2

(-1+2*M*R/(R^2+a^2*cos(Theta)^2))*dT^2+2*dT*dR+(R^2+a^2*cos(Theta)^2)*dTheta^2-4*M*R*a*sin(Theta)^2*dPhi*dT/(R^2+a^2*cos(Theta)^2)-2*a*sin(Theta)^2*dR*dPhi+((R^2+a^2)^2-(-2*M*R+R^2+a^2)*a^2*sin(Theta)^2)*sin(Theta)^2*dPhi^2/(R^2+a^2*cos(Theta)^2)

(2)

Set the metric and visually check it out (if its not right, adjust the line element above accordingly)

Setup(metric = (-1+2*M*R/(R^2+a^2*cos(Theta)^2))*dT^2+2*dT*dR+(R^2+a^2*cos(Theta)^2)*dTheta^2-4*M*R*a*sin(Theta)^2*dPhi*dT/(R^2+a^2*cos(Theta)^2)-2*a*sin(Theta)^2*dR*dPhi+((R^2+a^2)^2-(-2*M*R+R^2+a^2)*a^2*sin(Theta)^2)*sin(Theta)^2*dPhi^2/(R^2+a^2*cos(Theta)^2))

_______________________________________________________



`Coordinates: `[T, R, Theta, Phi]*`. Signature: `(`- - - +`)



_______________________________________________________



Physics:-g_[mu, nu] = Matrix(%id = 36893488152586874996)



_______________________________________________________



`Setting `*lowercaselatin_is*` letters to represent `*space*` indices`

(3)

To work with tetrads and everything related, there is a specialized package:

with(Tetrads)

_______________________________________________________



`Setting `*lowercaselatin_ah*` letters to represent `*tetrad*` indices`



(`Defined as tetrad tensors `(`see ?Physics,tetrads`)*`, `*`𝔢`[a, mu]*` , `*eta[a, b]*` , `)*gamma[a, b, c]*` , `*lambda[a, b, c]



(`Defined as spacetime tensors representing the NP null vectors of the tetrad formalism `(`see ?Physics,tetrads`)*`, `*l[mu]*` , `*n[mu]*` , `)*m[mu]*` , `*conjugate(m[mu])



_______________________________________________________



[IsTetrad, NullTetrad, OrthonormalTetrad, PetrovType, SegreType, TransformTetrad, WeylScalars, e_, eta_, gamma_, l_, lambda_, m_, mb_, n_]

(4)

For a brief description of each command, see the overview help page Tetrads

Set the signature, it follows the tetrad, by default it is of orthonormal type

Setup(signature = "-+++")

[signature = `- + + +`]

(5)

e_[]

Physics:-Tetrads:-e_[a, mu] = Matrix(%id = 36893488159811021868)

(6)

"IsTetrad(?)"

`Type of tetrad: `*orthonormal



true

(7)

Check its definition

e_[definition]

Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[b, `~mu`] = Physics:-Tetrads:-eta_[a, b]

(8)

Compute the components of this definition

TensorArray(Physics:-Tetrads:-e_[a, mu]*Physics:-Tetrads:-e_[b, `~mu`] = Physics:-Tetrads:-eta_[a, b], simplifier = simplify)

Matrix(%id = 36893488159798381732)

(9)

In the context of Physics you don't need to use a command to raise or lower an index, instead: just index with a covariant or contravariant index (the latter, by convention, are preceded by tilde ~). So to take one component of the tetrad, with either index covariant or contravariant, just input the tetrad with the desired indicesFor example, "`𝔢`[2]^(1) "

"e_[~1,2]"

I*(2*a^2*cos(Theta)^2+2*R^2)^(1/2)/(-2*a^2*cos(Theta)^2+4*M*R-2*R^2)^(1/2)

(10)

To compute the exterior derivative of an expression (see Physics:-ExteriorDerivative ), e.g. of  "`𝔢`[2]^(1) "

"ExteriorDerivative[mu](e_[~1,2])"

I*(-(1/2)*(2*a^2*cos(Theta)^2+2*R^2)^(1/2)*(4*a^2*cos(Theta)*Physics:-d_[mu](Theta, [X])*sin(Theta)+4*M*Physics:-d_[mu](R, [X])-4*R*Physics:-d_[mu](R, [X]))/(-2*a^2*cos(Theta)^2+4*M*R-2*R^2)^(3/2)+(1/2)*(-4*a^2*cos(Theta)*Physics:-d_[mu](Theta, [X])*sin(Theta)+4*R*Physics:-d_[mu](R, [X]))/((-2*a^2*cos(Theta)^2+4*M*R-2*R^2)^(1/2)*(2*a^2*cos(Theta)^2+2*R^2)^(1/2)))

(11)

To compute the ExteriorDerivative of a column of the tetrad, not just one component, do the same

ExteriorDerivative[mu](e_[1, nu])

(1/2)*Physics:-d_[mu](Physics:-Tetrads:-e_[1, nu], [X])-(1/2)*Physics:-d_[nu](Physics:-Tetrads:-e_[1, mu], [X])

(12)

To see the components of this expression always use TensorArray

TensorArray((1/2)*Physics[d_][mu](Physics:-Tetrads:-e_[1, nu], [X])-(1/2)*Physics[d_][nu](Physics:-Tetrads:-e_[1, mu], [X]))

Matrix(%id = 36893488159805085084)

(13)

You can also play around with these things, e.g. set a tensor whose components are given by (12)

T[mu, nu] = (1/2)*Physics[d_][mu](Physics:-Tetrads:-e_[1, nu], [X])-(1/2)*Physics[d_][nu](Physics:-Tetrads:-e_[1, mu], [X])

T[mu, nu] = (1/2)*Physics:-d_[mu](Physics:-Tetrads:-e_[1, nu], [X])-(1/2)*Physics:-d_[nu](Physics:-Tetrads:-e_[1, mu], [X])

(14)

Define(T[mu, nu] = (1/2)*Physics[d_][mu](Physics:-Tetrads:-e_[1, nu], [X])-(1/2)*Physics[d_][nu](Physics:-Tetrads:-e_[1, mu], [X]))

`Defined objects with tensor properties`



{Physics:-D_[mu], Physics:-Dgamma[mu], Physics:-Psigma[mu], Physics:-Ricci[mu, nu], Physics:-Riemann[mu, nu, alpha, beta], T[mu, nu], Physics:-Weyl[mu, nu, alpha, beta], Physics:-d_[mu], Physics:-Tetrads:-e_[a, mu], Physics:-Tetrads:-eta_[a, b], Physics:-g_[mu, nu], Physics:-Tetrads:-gamma_[a, b, c], Physics:-gamma_[i, j], Physics:-Tetrads:-l_[mu], Physics:-Tetrads:-lambda_[a, b, c], Physics:-Tetrads:-m_[mu], Physics:-Tetrads:-mb_[mu], Physics:-Tetrads:-n_[mu], Physics:-Christoffel[mu, nu, alpha], Physics:-Einstein[mu, nu], Physics:-LeviCivita[alpha, beta, mu, nu], Physics:-SpaceTimeVector[mu](X)}

(15)

Compute now any component of this tensor, e.g. T[`~1`, 2]

"T[~1, 2]"

(4*I)*M*a^2*(-sin(Theta)^2*cos(Theta)^4*a^4-cos(2*Theta)*cos(Theta)^4*a^4+2*M*sin(Theta)^2*cos(Theta)^2*R*a^2+a^4*cos(Theta)^4+M*cos(2*Theta)*cos(Theta)^2*R*a^2-2*M*sin(Theta)^2*R^3-M*R*a^2*cos(Theta)^2+R^4*sin(Theta)^2-M*cos(2*Theta)*R^3+cos(2*Theta)*R^4+M*R^3-R^4)/((R^2+a^2*cos(Theta)^2)*(2*a^2*cos(Theta)^2+2*R^2)^(3/2)*(-2*a^2*cos(Theta)^2+4*M*R-2*R^2)^(3/2))

(16)



Download WithPhysicsTetrads.mw

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

In the latest Maplesoft Physics Updates (v.1235) there is a fix to "not placing the default nonnegint assumption" I mentioned a couple of replies above. So with the latest Physics Updates for Maple 2022, we now get

> D[1 $ j, 2 $ k](f)(x, y);  # computes both derivatives, x$j and y$k

                  /   k                                                 /

                  | -----                                               |

                  |  \                                      (2 j - _k1) |

pochhammer(-j, j) |   )    binomial(k, _k1) GAMMA(1 + 2 j) y            | ...

                  |  /                                                  |

                  | -----                                               |

                  |_k1 = 0                                              |

                  \                                                     \

                                     ...

> eval(value(eval(%, [ j = 2, k = 4 ])), y = 0);

                                       6



PS: @Carl Love, although I see the motivation for your comment, I don't foresee adding to the diff command an option like "return a piecewise with all the cases".  The design of diff is to return a default value, and handle assumptions when possible - only that. It is similar to how the conversion network for mathematical functions works (see ?convert, to_special_function).

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

@vv
I pointed out that the symbolic differentiation result, for symbols j and k, is correct. You objected to that. I only replied showing that, indeed, the result is correct. That closes the question.

Next you pointed out that the symbolic differentiation result is fragile. That concept is debatable. I do agree though, with a previous comment by you, that the most common situation is j, k nonnegint; so if choosing a way to express the result using GAMMA functions, do that for the most common case. The symbolic differentiation code is already doing that. But not in one branch of a subroutine, and the problem posted hits that branch. Although the result is correct, it can be better. It is something to adjust.

But then you come up with applying blindly the manipulation I used for the default output, after (you) using the opposite assumptions. With due respect, @vvI don't see your point. You realize that if the result contains GAMMA as in this example, under direct evaluation it will either work with j negint, or for j posint, and not with both at the same time.

Add to that my opinion, that returning piecewise functions all around is not a convenient idea. Instead, I prefer presenting results with a convenient default and leave to the user to use assumptions for the other cases. Also relevant: understand that having Sums, and especially in the higher-order symbolic differentiation case, the results may require additional algebraic manipulations when evaluating the symbols involved at some values; typically, cases where correctness would require using limits or removing apparent singularities.

Returning to your example assuming j::nonegint, k::nonegint (above this reply), the manipulation after ex1 is as follows:

ex2 := simplify(eval(ex1, [j=2,k = 4, Sum = add]), GAMMA);
simplify(eval(ex2, [y=0]));
                                              6


So, the result by the symbolic differentiation code is also correct when assuming j::nonegint, k::nonegint.

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

@vv

It is about removable/apparent singularities.

f := proc (x, y) options operator, arrow; 1/(2+x*y^2) end proc

(D[`$`(1, j), `$`(2, k)](f))(x, y)

pochhammer(-j, j)*(Sum(binomial(k, _k1)*(-1)^_k1*y^(-_k1)*(y^2)^j*GAMMA(-2*j+_k1)*(diff((x*y^2+2)^(-1-j), [`$`(y, k-_k1)]))/GAMMA(-2*j), _k1 = 0 .. k))

(1)

We know that, for x = 0, y = 0, j = 2, k = 4 the value of (D[`$`(1, j), `$`(2, k)](f))(x, y)is 6, the issue is whether the answer above is or is not correct:



simplify(eval(pochhammer(-j, j)*(Sum(binomial(k, _k1)*(-1)^_k1*y^(-_k1)*(y^2)^j*GAMMA(-2*j+_k1)*(diff((x*y^2+2)^(-1-j), [`$`(y, k-_k1)]))/GAMMA(-2*j), _k1 = 0 .. k)), [k = 4, Sum = add]), GAMMA)

8*(x*y^2+2)^(-1-j)*(32*j^4+(-208*x*y^2-96)*j^3+(366*x^2*y^4+216*x*y^2+88)*j^2+(-180*x^3*y^6+18*x^2*y^4-56*x*y^2-24)*j+15*x^4*y^8-60*x^3*y^6+12*x^2*y^4)*pochhammer(-j, j)*(y^2)^j/((x*y^2+2)^4*y^4)

(2)


eval(8*(x*y^2+2)^(-1-j)*(32*j^4+(-208*x*y^2-96)*j^3+(366*x^2*y^4+216*x*y^2+88)*j^2+(-180*x^3*y^6+18*x^2*y^4-56*x*y^2-24)*j+15*x^4*y^8-60*x^3*y^6+12*x^2*y^4)*pochhammer(-j, j)*(y^2)^j/((x*y^2+2)^4*y^4), [j = 2, x = 0])

6``

(3)

NULL

Download Symbolic_differentation_is_correct.mw

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

Hi @vv

The problem you point at is in `eval/Sum`. Not in sum and not in D, both work correctly, that is why D[1$2,2$4](f)(0,0) returns 6, correct. To see the problem in `eval/Sum` try

f := (x, y) -> 1/(2 + x*y^2):
D[1 $ j, 2 $ k](f)(x, y);  # correct result for the jth and kth symbolic derivative

                                ...

eval(%, [x = 0, y = 0]);  # problem in `eval/Sum`
                                   /   k     \
                                   | -----   |
                                   |  \      |
                 pochhammer(-j, j) |   )    0|
                                   |  /      |
                                   | -----   |
                                   \_k1 = 0  /



Regarding your first question, the command to use is Library:-SubstituteOperator. Your reply indirectly introduces two more questions, one about reordering noncommuting operators, the command is SortProducts, and the other one is about commutativity of indexed quantum operators - use noncommutative variables instead, or quantum tensorial operators.



Finally, when you present a power as in A[1]*B[2]*B[2] = A[1]*B[2]^2, the code was requiring an extra argument to act on powers. I changed that default behavior so it now acts on powers automatically (unless you explicitly specify otherwise) - so for that you need to update to the latest Maplesoft Physics Updates version 1126. The rest of what follows doesn't require that.



Formulating the problem,

with(Physics); Setup(quantumoperators = {A, B, C})

[quantumoperators = {A, B, C}]

(1)

Setup(algebrarules = {%Commutator(A[m], B[n]) = C[m+n]})

[algebrarules = {%Commutator(A[m], B[n]) = C[m+n]}]

(2)

The answer to your original question is Library:-SubstituteOperator

Library:-SubstituteOperator(A[1]*B[2] = 5, A[1]*B[2]*B[3]+C[3])

5*B[3]+C[3]

(3)

Next question, when you are substituting into noncommutative operators, the order of the operands is relevant. For example, this doesn't work:

('Library:-SubstituteOperator')(A[1]*B[2] = 5, A[1]*B[2]*B[3]+C[3])

Physics:-Library:-SubstituteOperator(Physics:-`*`(A[1], B[2]) = 5, Physics:-`*`(B[2], A[1], B[3])+C[3])

(4)

Physics[Library]:-SubstituteOperator(Physics[`*`](A[1], B[2]) = 5, Physics[`*`](B[2], A[1], B[3])+C[3])

Physics:-`*`(B[2], A[1], B[3])+C[3]

(5)

Why? Because A[1]*B[2] <> A[1]*B[2]. So first you'd need to sort products, and in doing so any commutator rule is automatically taken into account. For example in view of

(%Commutator = Commutator)(A[2], B[1])

%Commutator(A[2], B[1]) = C[3]

(6)

The following two-step operation works

SortProducts(Physics[`*`](B[2], A[1], B[3])+C[3], [A[1], B[2]])

Physics:-`*`(A[1], B[2], B[3])-Physics:-`*`(C[3], B[3])+C[3]

(7)

Library:-SubstituteOperator(A[1]*B[2] = 5, Physics[`*`](A[1], B[2], B[3])-Physics[`*`](C[3], B[3])+C[3])

5*B[3]-Physics:-`*`(C[3], B[3])+C[3]

(8)

One could make these two steps be automatically be only one step, at the cost of having less control; something to think about.



Next, about commutation:

Library:-Commute(B[1], B[2])

true

(9)

Why is that? Because setting B as a quantum operator results in this action on kets.

B[1].Ket(B, m, n)

m*Physics:-Ket(B, m, n)

(10)

B[2].Ket(B, m, n)

n*Physics:-Ket(B, m, n)

(11)

That is, B[1] and B[2] are operators that act on disjointed spaces, the indexation is used to select the corresponding eigenvalue in a tensor product of states Ket(B, m, n), therefore B[1] and B[2] commute.



You could avoid this subtlety if you work with noncommutative variables as opposed to quantum operators. For example

Setup(noncommutativeprefix = Z)

[noncommutativeprefix = {Z}]

(12)

Library:-Commute(Z[1], Z[2])

false

(13)

You can also give a different meaning to quantum operators B[1] and B[2] and, in doing so, indicate they do not commute. Suppose you know the dimension of the index, for example 3; e.g. angular momentum. Define a tensor with its components here I use a different letter but any letter is as good

Setup(spaceindices = lowercaselatin_is, op = L, tensors = L[m])

`* Partial match of '`*op*`' against keyword '`*quantumoperators*`' `



_______________________________________________________



[quantumoperators = {A, B, C, L}, spaceindices = lowercaselatin_is, tensors = {Physics:-Dgamma[mu], L[m], Physics:-Psigma[mu], Physics:-d_[mu], Physics:-g_[mu, nu], Physics:-gamma_[i, j], Physics:-LeviCivita[alpha, beta, mu, nu]}]

(14)

So now

Library:-Commute(L[1], L[2])

false

(15)

You see the dimension around:

L[m]^2

Physics:-`*`(L[m], L[`~m`])

(16)

SumOverRepeatedIndices(Physics[`*`](L[m], L[`~m`]))

Physics:-`*`(L[1], L[`~1`])+Physics:-`*`(L[2], L[`~2`])+Physics:-`*`(L[3], L[`~3`])

(17)

Now suppose you do not know the dimension. You can still define tensor of a space with unknown dimension, here generally called "gauge". So define corresponding indices and a tensorial quantum operator F[a] of that space

Setup(gaugeindices = lowercase_ah, op = F, tensors = F[a])

`* Partial match of '`*op*`' against keyword '`*quantumoperators*`' `



_______________________________________________________



[gaugeindices = lowercaselatin_ah, quantumoperators = {A, B, C, F, L}, tensors = {Physics:-Dgamma[mu], F[a], L[m], Physics:-Psigma[mu], Physics:-d_[mu], Physics:-g_[mu, nu], Physics:-gamma_[i, j], Physics:-LeviCivita[alpha, beta, mu, nu]}]

(18)

Again, the components don't commute

Library:-Commute(F[1], F[2])

false

(19)

This time the dimension is not known, so for example the sum over the repeated indices cannot be performed:

F[a]^2

Physics:-`^`(F[a], 2)

(20)

SumOverRepeatedIndices(Physics[`^`](F[a], 2))

Physics:-`^`(F[a], 2)

(21)

Still, tensorial simplification operations continue working

F[a]^2-F[b]^2

Physics:-`^`(F[a], 2)-Physics:-`^`(F[b], 2)

(22)

Simplify(Physics[`^`](F[a], 2)-Physics[`^`](F[b], 2))

0

(23)

KroneckerDelta[a, b]*F[b]

Physics:-KroneckerDelta[a, b]*F[b]

(24)

Simplify(Physics[KroneckerDelta][a, b]*F[b])

F[a]

(25)

Now to handle powers

A[1]*B[2]*B[2]-C[3]*B[3]+C[3]

Physics:-`*`(A[1], Physics:-`^`(B[2], 2))-Physics:-`*`(C[3], B[3])+C[3]

(26)

without updating to the latest Physics Updates, you'd need to add the word 'true' at the end of the arguments passed. After installing the latest Physics updates that is not necessary:

Library:-SubstituteOperator(A[1]*B[2] = 5, Physics[`*`](A[1], Physics[`^`](B[2], 2))-Physics[`*`](C[3], B[3])+C[3])

5*B[2]-Physics:-`*`(C[3], B[3])+C[3]

(27)


PS: when using the Green Arrow to insert a worksheet, you can also ask for the contents to be shown, and filename.maple are not recommended for upload; use filename.mw instead.

Download SubstituteOperator_(II).mw

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

@etian2

But then you need to write the preamble properly - and that is not what you are doing. One workaround is for you to convert any worksheet, get the right preamble, then use it as a template. If that doesn't work AND you keep not posting a worksheet (do you expect people to start reading your image and trying to reproduce by typing etc.?), there is no chance.

Anyway, this is my last reply to this thread.

1 2 3 4 5 6 7 Last Page 1 of 54
