The documentation of SubgroupLattice says:

The algorithm used does not find any perfect subgroups of G, other than potentially G itself, its soluble residual, and the trivial group. If the soluble residual of G is of size at least 360, then it may contain other nontrivial perfect subgroups. These will not be found by the algorithm.

Maybe there are other omissions.


The denominator has many very small values ==> large roundoff errors.
Increasing Digits (e.g. Digits:=15) solves the problem.

Just replace in param1,...,param4:  alpha*gamma=0.004;   with   gamma=0.004/alpha;
(or use algsubs).

Advices:
- don't load packages which are not needed
- gamma is a Maple constant, don't use it as a variable
- linalg is deprecated; use LinearAlgebra instead.



convert(EllipticK(x), Int):
eval(%,x=1); value(%);

          infinity

with(GroupTheory):
g:=DrawSubgroupLattice(SmallGroup(200, 31), labels = ids, output=graph):
GraphTheory:-DrawGraph(g, size=[1200,800]);

Execute

pp:=interface(prettyprint=1);

before Generators(...), then copy.
To restore the old settings:

interface(prettyprint=pp):
