Dear Users!

Hope you would be fine. I want to construct system of equations by comparing the likes powers of x^i*y^j*t^k1*exp(k2*eta) for an expression H1 present in attached file. Please see the fix my problem. I shall be very thankful for your kind help.

Help.mw

From  time to tiime Malel emits a sort of "Boiing" noise when I make a keyboard error. I am not sure exaclty when it does this, but it is loud. Is it possible to turn it off? I have looked quite extensively and cannot find out anything.

How to compute inverse of a square matrix in maple?

Like below matrix:

Matrix(6, 6, [[1/EE__1, -nu__21/EE__2, -nu__31/EE__3, 0, 0, 0.], [-nu__12/EE__1, `#mn("1")`/EE__2, -nu__32/EE__3, 0, 0, 0.], [-nu__13/EE__1, -nu__23/EE__2, `#mn("1")`/EE__3, 0, 0, 0], [0, 0, 0, 1/GG__23, 0., 0], [0, 0, 0, 0., 1/GG__13, 0], [0., 0., 0, 0, 0, 1/GG__12]])

Maple help say there is a mode n number, but what actually is it?

In the following problem at two example are given. For Z=2 the sum is converging whereas at Z=4 it is not converging. Thank you

PROBLEM.mw

I have a problem writing a program for the numerical solution of nonlinear volterra integral equation using the method of reproducing kernel space. I have my algorithm as well as the program I tried to write, though they are full of error messages. Please could anyone give me a clue on how to go about my challenges. The algorithm is as follows:

Step 1. Fix 𝑎 ≤ 𝑥 and 𝑡 ≤ 𝑏.
If 𝑡 ≤ 𝑥, set 𝑅𝑥(𝑡) = 1 − 𝑎 + 𝑡.
Else set 𝑅𝑥(𝑡) = 1 − 𝑎 + 𝑥.
Step 2. For 𝑖 = 1, 2, . . . , 𝑚 set 𝑥_i = (𝑖 − 1)/(𝑚 − 1).

Set 𝜓_i(𝑥) = 𝐿_t𝑅𝑥(𝑡)|𝑡=𝑥_i .
Step 3. Set 𝑢₀(𝑥₁) = 𝑢(𝑥₁).
Step 4. For 𝑖 = 1, 2, . . . , 𝑚 set 𝛾_ij = [𝜓^-1]_ij.
Step 5. 𝑛 = 1.
Step 6. Set S_n = Σ𝑛
𝑘=1 𝛾_nk𝑢_k-1(𝑥_k).
Step 7. Set 𝑢_n(𝑥) = Σ𝑛
𝑖=1 S_i𝜓_i(𝑥).
Step 8. If 𝑛 < 𝑚then set 𝑛 = 𝑛 + 1 and go to step 6.
Else stop.

So I have this system of equations with which I am not sure if the result is the same or not using "series" and "limit" or what is going on here.

I hope it is clear what I mean.

Download Mapleprimes_-_Ionproduct.mw

As an example, the two-dimensional Array created by

A := Array(triangular[upper], 1..100, 1..100);

has both indexing function and storage "triangular[upper]", which is fine. However, the attempt

B := Array(triangular[upper], 1..100, 1..100, 1..100);

to make a three-dimensional analogue did not work: It returns "Error, triangular[upper] indexing is only valid with 2 dimensions". A similar error message is returned when I replace "triangular[upper]" by "symmetric".

(For definiteness, by a higher-dimensional symmetric Array I would like to understand an Array with entries that are invariant under every permutation of their indices. Similarly, I would call the Array upper-triangular if only its entries with non-decreasing indices can be non-zero.)

For a first solution attempt, I mimic a higher dimensional upper-triangular Array by instead creating a multiply nested one-dimensional Array, where the one-dimensional subarrays become shorter and shorter. I did some preliminary testing with CodeTools[Usage] and the memory and timing results seem to compare favorably to naively using standard rectangular Arrays.

It seems more natural to write my own indexing function. However, I am not sure how to write a suitable corresponding storage function, as the documentation on that latter subject mentions only Vectors and Matrices. Is it possible and advisable to write my own storage function, or is there yet another more natural and memory-efficient way to store higher-dimensional structured Arrays (with symbolic data) in Maple?

Thank you very much for any insights, particularly documentation pointers.

Sebastiaan Janssens.

is there example data that can verify maxwell equations?

How to calculate determinant of a cube matrix ?

is there function to calculate 3x 3x 3 cube determinant?

How to proof classical and quantum both p summation equal to one in maple?

with(linalg):
A := matrix([[1,0],[0,1]]);
AA := exponential(t*A);

A := matrix([[-i/h,0],[0,-i/h]]);
AA := exponential(t*A);
Error, (in evalf/matrixexp) cannot determine if this expression is true or false: 0.9482523555e34*abs(t*i) < 1

arctan(sqrt(3)/2/(1/2));
cos(Pi/3) + i*sin(Pi/3);

exp(i*Pi/3);

cos(Pi/3) + i*sin(Pi/3) - exp(i*Pi/3);

with(ScientificConstants):
Constant(hbar);
h := evalf(%);
dsolve(diff(s(t),t) + i/h*s(t)=0,s(t));
dsolve(diff(s(t),t) + i*s(t)=0,s(t));


after solve differential equation, there is no Pi/3,

can s(t) be a matrix ?

where do Pi/3 come from?

then i try Ket

with(Physics);
K1 := Ket(&psi;t);
dsolve(diff(K1,t) + i/h*K1=0,K1);

Error, invalid neutral operator;
Ket is matrix or complex number ?

and how to solve?

is possible to solve these partial differential equations in maple via pdsolve?

Thanks

In an unrelated thread, I provided the OP with some 1-D code, which contained the Array definition

TC:= Array(0...1001, fill=0)

Note the existence of three '.' characters in the range specification. This was a typo on my part, or my '.' key bounced, or something. The code containing the above definition "worked" with no problem, which, presumably, was why I didn't notice.

The Maple help does state (my emphasis)

Note that more than two dots in succession are also parsed as the range (..) operator.

although I wasn't making use of this fact - I just screwed up when typing the original.

The OP preferred to use 2-D input, and used cut-and-paste to transfer the above code, resulting in 2-D input, which is where the fun started. It seems(?) that when using 2-D input, more than two dots in succession is only interpreted as a straightforward range, if the total number of dots is even.

If the total number of dots is odd, then it appears(?) as if the 'final' dot is associated with the second number in the range as a 'decimal point', (so producing .1001 in the above example). This is then 'coerced/rounded' to an integer - ie it becomes '0', and the above Array definition is interpreted as

TC:= Array(0..0, fill=0)

Consequences in the following code are left to your imagination

Worth an SCR?

K := simplify(C, 'size');
      5                                                  4
lambda  + (-a__11 - a__33 - a__44 - a__55 - a__22) lambda  +

  ((a__44 + a__33 + a__22 + a__11) a__55

   + a__44 (a__33 + a__22 + a__11) + (a__33 + a__22) a__11

                                      3
   + a__33 a__22 - a__32 a__23) lambda  + (((-a__33 - a__22

   - a__11) a__44 + (-a__33 - a__22) a__11 - a__33 a__22

   + a__32 a__23) a__55

   + ((-a__33 - a__22) a__11 - a__33 a__22 + a__32 a__23) a__44

   + (-a__22 a__33 + a__23 a__32) a__11

                                              2
   - a__32 (a__13 a__21 + a__24 a__43)) lambda  + ((((a__33

   + a__22) a__11 + a__33 a__22 - a__32 a__23) a__44

   + (a__22 a__33 - a__23 a__32) a__11

   + a__32 (a__13 a__21 + a__24 a__43)) a__55

   + ((a__22 a__33 - a__23 a__32) a__11 + a__13 a__21 a__32) a__44

   + a__32 (a__11 a__43 a__24 - a__21 (a__14 a__43 + a__15 a__53)

  )) lambda + (((-a__22 a__33 + a__23 a__32) a__11

   - a__13 a__21 a__32) a__44

   - a__43 a__32 (a__11 a__24 - a__14 a__21)) a__55

   - a__15 a__21 a__32 (a__43 a__54 - a__44 a__53)

u := [coeffs(K, [lambda], 'l')];
[(((-a__22 a__33 + a__23 a__32) a__11 - a__13 a__21 a__32) a__44

   - a__43 a__32 (a__11 a__24 - a__14 a__21)) a__55

   - a__15 a__21 a__32 (a__43 a__54 - a__44 a__53), 1,

  -a__11 - a__33 - a__44 - a__55 - a__22, (a__44 + a__33 + a__22

   + a__11) a__55 + a__44 (a__33 + a__22 + a__11)

   + (a__33 + a__22) a__11 + a__33 a__22 - a__32 a__23, ((-a__33

   - a__22 - a__11) a__44 + (-a__33 - a__22) a__11 - a__33 a__22

   + a__32 a__23) a__55

   + ((-a__33 - a__22) a__11 - a__33 a__22 + a__32 a__23) a__44

   + (-a__22 a__33 + a__23 a__32) a__11

   - a__32 (a__13 a__21 + a__24 a__43), (((a__33 + a__22) a__11

   + a__33 a__22 - a__32 a__23) a__44

   + (a__22 a__33 - a__23 a__32) a__11

   + a__32 (a__13 a__21 + a__24 a__43)) a__55

   + ((a__22 a__33 - a__23 a__32) a__11 + a__13 a__21 a__32) a__44

   + a__32 (a__11 a__43 a__24 - a__21 (a__14 a__43 + a__15 a__53)

  )]
u[1] = C__5;
(((-a__22 a__33 + a__23 a__32) a__11 - a__13 a__21 a__32) a__44

   - a__43 a__32 (a__11 a__24 - a__14 a__21)) a__55

   - a__15 a__21 a__32 (a__43 a__54 - a__44 a__53) = C__5
C__1 = u[3];
         C__1 = -a__11 - a__33 - a__44 - a__55 - a__22
C__2 = u[4];
   C__2 = (a__44 + a__33 + a__22 + a__11) a__55

      + a__44 (a__33 + a__22 + a__11) + (a__33 + a__22) a__11

      + a__33 a__22 - a__32 a__23
C__3 = u[5];
C__3 = ((-a__33 - a__22 - a__11) a__44 + (-a__33 - a__22) a__11

   - a__33 a__22 + a__32 a__23) a__55

   + ((-a__33 - a__22) a__11 - a__33 a__22 + a__32 a__23) a__44

   + (-a__22 a__33 + a__23 a__32) a__11

   - a__32 (a__13 a__21 + a__24 a__43)
C__4 = u[6];
C__4 = (((a__33 + a__22) a__11 + a__33 a__22 - a__32 a__23) a__44

   + (a__22 a__33 - a__23 a__32) a__11

   + a__32 (a__13 a__21 + a__24 a__43)) a__55

   + ((a__22 a__33 - a__23 a__32) a__11 + a__13 a__21 a__32) a__44

   + a__32 (a__11 a__43 a__24 - a__21 (a__14 a__43 + a__15 a__53)

  )


I am trying to solve a diffusion equation with a potential term that has an integral in it. The equation has the following form:

PDE := diff(g(x, t), t) = diff((beta(x, t)+diff(g(x, t), x)), x),

with the function beta:

beta := proc (x, t) options operator, arrow; int(exp(-abs(x-y))*g(y, t), y = -infinity .. +infinity) end proc

The boundary conditions for the function g(x,t) are simply assumed to be a zero-centered Gaussian in space (i.e. in x). So it is unity for x=0 and zero for the outer boundary that we can set as x=L.

The problem is easily solved if the function beta is not an integral, but in the current form I get the following error:
*******
Error, (in pdsolve/numeric/process_PDEs) inconsistent dependencies in PDEs: g(x, t) v.s. g(y, t)

*******

So it does not like the dummy variable in the function g.

I can not write an additional PDE for beta because my Kernel is an exponential so the integral never goes away. Anyone with a way to solve this?

ADDENDUM: I have now copied the scriptPDE_DIFFUSION_INTEGRAL.mw


Download PDE_DIFFUSION_INTEGRAL.mw

below.
