Executing HelpTools:-Database:-ConvertAll(): produced file DirectSearch.help apparently without content. How can all content within DirectSearch.hdb be converted to a .help file accessible through help in Maple 2016?

In a post of April 15, 2013 by Kitonum, the procedure named Picture accepts a list of polygon segments, creates a plot of these as a 2D polygon's boundaries and fills the polygon with a color.

The code below attempts to modify Picture to produce a 3D filled polygon in a plane parallel to the xy plane.

When invoked by the code below the procedure, the filling color conforms to the straight line boundaries but overflows the curved, parabolic boundary. How can this be corrected?

Picture:=proc(L, C, N::posint:=100, Boundary::list:=[linestyle=1])

 local i, var, var1, var2,e, e1, e2,e3, P, h ;

 global Q,Border;

 for i to nops(L) do

#` set P`[i] = list of points for each segment.

#` for a segment defined as a list of points, P[i] = the segment's definition`

#` for a curve definition, approximate it with a list of [x,y] points of its function evaluated at N even intervals in its

# range`

  if type(L[i],listlist(algebraic))  then P[i]:=op(L[i]);   else

  #` for curve def'n, set var = def'n and h= `(variable range)/(2)

  var:=lhs(L[i,2]);  var1:=lhs(rhs(L[i,2]));  var2:= rhs(rhs(L[i,2])); h:=(var2-var1)/(N);

  #` for function def'n, set e=function`

 if type(L[i,1], algebraic) then  e:=L[i,1];

  #` for polar function r=f(t) create N values of the [cos*r,sin*r] i.e. the equivalent [x,y] values for r valued at N even

  # divisions of its range`

 if nops(L[i])=3 then P[i]:=seq(subs(var=var1+h*i,[e*cos(var), e*sin(var)]), i=0..N);  else

    #` for non-polar function y=f(x) create N values of [x,y] for x values at N even divisions of its range`

 P[i]:=seq([var1+h*i, subs(var=var1+h*i,e)], i=0..N)  fi;  else

 #` for parametric function [f`(t),g(t)] create N values of [f(t),g(t)] for t values at N even divisions of its range.

     e1:=L[i,1,1];  e2:=L[i,1,2];

#` P`[i]:=seq(subs(var=var1+i*h,[e1, e2]), i=0..N):

 P[i]:=seq([subs(var=var1+i*h,e1), subs(var=var1+i*h,e2),0], i=0..N) fi; fi; od;  #`  MODIFIED FOR 3 D `[f(t), g(t), 0]

  Q:=[seq(P[i], i=1..nops(L))];

 Border:=plottools[curve]([op(Q), Q[1]],  op(Boundary));

     #` the shaded figure is a polygon whose vertices are Q, whose interior color is C`

 #` return a list of the polygon and its border`

   [plottools[polygon](Q, C),  Border];

 end proc:

L := [[[0, 0, 0], [0, 1, 0]], [[x, x^2+1, 0], x = 0 .. 2], [[2, 5, 0], [2, 2, 0]], [[x, x, 0], x = 2 .. 0]]:

plots[display](Picture(L, color = yellow), axes = normal, scaling = constrained)

I have downloaded the zip file for CalcP7, unzipped it, and can access its commands in a worksheet after issuing the command with(CalcP7), but "No Matches Found" displays when entering the command ?CalcP7. The download included a file named "aplication" (one "p") of type HDB, but Maple15 can't seem to access its contents.

Are CalcP7's help pages displayable? If so, what is necessary to access them?

I have had no trouble downloading the user package DirectSearch and accessing both its commands and its help pages.

plots[implicitplot3d](max(-x+y+z, x-y+z, x+y-z) = 1.0, x = 0 .. 1, y = 0 .. 1, z = 0 .. 1);

The help page for max does not explain or show an example of max(sequence of expressions)= a constant.

PrimesQuestion.mw

Please let me know if this link correctly accesses my worksheet. If not, I will copy its contents into this question.

Which ODE in the worksheet, if any, provides the correct answer?
